LEWMAR V3 GD/GO windlass, 1000W

Name: LEWMAR V3 GD/GO windlass, 1000W
Brand: Osculati
SKU: G0250
Price: 1525.8 EUR
Availability: OutOfStock

Codice prodotto: G025091

Lewmar V3 windlass gypsy

Out-of-Stock

€1,525.80

Codice variante selezionata G025091

Description

- Rope/chain gypsy.

- AISI316 stainless steel deck unit.

- FastFit: new patented motor mounting option for quicker installation.

- Fall Safe anchor lock.

- Modern design.

- ready to fit chain counter sensor.

- IP68 waterproof unit.

Catalogo PDF Download (297B)

Choose the model

Code	Add to cart		Version	Motor - V	Motor - W	Variant Choice	Weight	For boats	Current draw A	Gypsy - chain Ø mm	Gypsy - Line Ø mm	Pull kg - max	Pull kg - continuous	Recommended circuit breaker A	Single parts - Only gypsy	Single parts - Only solenoid	Line speed m / min - max	Line speed m / min - continuous	Single parts - Only deck unit	Single parts - Only motor/gearbox	Price
G025091	add to cart	-	-	-	-	Outdoor unit only for V2/V3 low	-	-	-	-	-	-	-	-	-	-	-	-	-	-	€1,525.80
G025092	add to cart	-	-	-	-	Outdoor unit only for V2/V3 high	-	-	-	-	-	-	-	-	-	-	-	-	-	-	€1,778.90
G025093-012	add to cart	-	-	-	-	12V motor/gearbox only	-	-	-	-	-	-	-	-	-	-	-	-	-	-	€1,900.40
G025094-024	add to cart	-	-	-	-	24V motor/gearbox only	-	-	-	-	-	-	-	-	-	-	-	-	-	-	€1,900.40
G025010	add to cart	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	€997.60
G025008-012	add to cart	-	GO	12	1000	Low - 12V - Chain Ø8 mm	21	12 to 16 m	85	8	12-16	890	223	110	[02.519.08]	[02.590.01]	28	18	[02.511.01]	[02.516.12]	€2,935.50
G025010-012	add to cart	-	GO	12	1000	Low - 12V - Chain Ø10 mm	21	12 to 16 m	85	10	12-16	890	223	110	[02.519.10]	[02.590.01]	28	18	[02.511.01]	[02.516.12]	€2,929.80
G025008-112	add to cart	-	GD	12	1000	High - 12V - Chain Ø8 mm	23	12 to 16 m	85	8	12-16	890	223	110	[02.519.08]	[02.590.01]	28	18	[02.511.02]	[02.516.12]	€3,171.70
G025010-112	add to cart	-	GD	12	1000	High - 12V - Chain Ø10 mm	23	12 to 16 m	85	10	12-16	890	223	110	[02.519.10]	[02.590.01]	28	18	[02.511.02]	[02.516.12]	€3,166.00
G025008-024	add to cart	-	GO	24	1000	Low - 24V - Chain Ø8 mm	21	12 to 16 m	60	8	12-16	1020	223	90	[02.519.08]	[02.590.02]	30	20	[02.511.01]	[02.516.24]	€2,942.60
G025010-024	add to cart	-	GO	24	1000	Low - 24V - Chain Ø10 mm	21	12 to 16 m	60	10	12-16	1020	223	90	[02.519.10]	[02.590.02]	30	20	[02.511.01]	[02.516.24]	€2,936.90
G025008-124	add to cart	-	GD	24	1000	High - 24V - Chain Ø8 mm	23	12 to 16 m	60	8	12-16	1020	223	90	[02.519.08]	[02.590.02]	30	20	[02.511.02]	[02.516.24]	€3,178.80
G025010-124	add to cart	-	GD	24	1000	High - 24V - Chain Ø10 mm	23	12 to 16 m	60	10	12-16	1020	223	90	[02.519.10]	[02.590.02]	30	20	[02.511.02]	[02.516.24]	€3,173.10
G025001	add to cart	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	€1,005.80
